Bus Duct
We had a strong Busduct Solution Division and would like to present our fleet in the following
Specifications.
-
Most ideal for transformer to Switchgear connections.
-
Current ratings up to 5000 Amps.
-
Enclosure and Busbar Material as Per customer's requirement
-
Enclosure Protection up to IP 55
-
Space heaters with thermostat controls as per specification.
-
Filter Drain Plugs and silica gel breathers as required
-
Routine and Type Tests as per relevant Indian standards.
-
Supply, Erection, Testing & Commissioning on a Turnkey Basis
Manufacturing Range of Cubicles
-
PT & SP cubicle
-
Neutral grounding cubicle
-
Terminal Boxes / Cubicle
-
Generator Auxiliary compartment
​
Special Services
To undertake renovation and modification of Bus ducts at the project site to suit the Generator
Transformer connection.
Isolated Phase Busducts
-
Medium and High-Power Generating leads in power stations for voltages 12kV to 36kV and currents up to 20,000 Amps.
-
Suitable in highly polluted or humid environments both for Indoor and Outdoor operations.
-
Designed to withstand high short circuit currents.
-
Natural cooled conductors and enclosures.
-
High conductivity AI Alloy conductors and enclosures.
-
Three or single insulator supporting system with Epoxy cast resin/porcelain insulators.
-
Conductors/Enclosures compensators to eliminate problems of expansion forces.
-
Inspection and maintenance of windows for cleaning and easy replacement of insulators.
-
Pressurized system for extreme environmental conditions.
-
Type testing as per IS/ANSI standards.
-
Execution on a Turnkey Basis.
​
Resolving the problem of transmitting electrical energy under optimum conditions of efficiency, safety
and continuity of service is a major requirement.
The simple design of the LT Busduct system has been fully tested in the central power research institute
laboratories and every step of design, engineering, and manufacture is monitored by quality control
procedures.
-
11kV to 24kV
-
1000A to 20,000A
-
Isolated Phase Ducts
